P10 Outdoor Advertising Led Screen Full Color Big Screen video TV led wall
1.With the high quality raw material, mature process and scale production,the quality is ensured
2. All our outdoor LED display screen with high quality LED, Less dead lamps even used over 2-3 years .It can save much money for maintenance.
3.The brightness is high , can be over 6000 nits or higher , no problem at all even under direct sunlight
4.Our cabinet is designed with back covers at rear side for better waterproof function . There are side locks , waterproof power and signal connectors for easy installation ,depends on customer choice.
5.We have the most competitive prices based on all good material we use . Our quality is very repliable and we win very good reputation in the market .
TECHNICAL PARAMETER
| P10 FULL-COLOR TECHNICAL PARAMETER |
| Item | Parameter |
| Pixel Pitch | 10 mm |
| Pixel Density | 10000 dot/sqm |
| Pixel Configuration | 1R1G1B SMD3535 |
| Module Size | 320*160 mm |
| LED brand | R&G&B: EPISTAR |
| Cabinet type | opened/closed |
| Unit cabinet dimension | 960mm×960mm×100mm |
| Module Resolution | 32*16 dot |
| Cabinet Resolution | 96*96 dot |
| Weight | 20KG |
| Cabinet Material | SPCC |
| Viewing Distance | ≥10 m |
| Viewing Angle (Horizontal Axis) | 160° |
| Viewing Angle (Vertical Axis) | 160° |
| Refresh Rate | ＞1920Hz |
| Grey Scale | 65536 |
| Brightness | ≥6500cd/m2 |
| Max Power Consumption | 750 w/sqm |
| Average Power Consumption | 350 w/sqm |
| Drive Mode | 1/4 Scan Constant Current |
| Signal EMC | VGA,DVE, |
| Signal Transmission Mode | 568B |
| Network Cable | ≤100m, Multimode |
| Control Distance | optical fiber≤500m, Single mode optical |
| fiber | ≤20 kilometer |
| Lifespan | ≥10,0000 h |
| Waterproof Grade | Outdoor Use IP65 |
| Input Voltage | AC220V±10% 50-60HZ |
| Celsius | Degree:—10℃-40℃ |
| humidity:10 | 10—85%RH |
Application
1. Outdoor full-color led display media is widely used in public places, advertising, urban road networks, urban parking lots, railways, subways and other traffic guidance systems, highways, etc.
2. Outdoor LED display screens are widely used in finance, taxation, industry and commerce, post and telecommunications, sports, advertising, factories and mines, transportation, education systems, stations, terminals, airports, shopping malls, hospitals, hotels, banks, securities markets, construction markets, Auction houses, industrial enterprise management and other public places
Delivery date
| Quantity(Square Meters) | 1 - 50 | 51-100 | 101 - 200 | >200 |
| Est. Time(day) | 16 | 20 | 28 | To be negotiated |
